Seitz Heki
2 Rooflight -
Easy to Handle With Pneumatic Stays
The Seitz Heki 2 caravan rooflight
is made from robust
and weather-proof ASA that has been developed specially for caravans. The large
opening allows plenty of light and optimal ventilation.
The double glazed acrylic panel is easily opened with the metal bar handle
as the pane is held open by the pneumatic stays for your comfort. Locked
in the bad weather setting, rain cannot penetrate into the caravan and
wind cannot lift the panel in secured position.
The large opening of approx.
780 x 530 mm allows plenty of light and also optimal ventilation.
Easy installation along or
across the vehicle roof. Installation requires a flat surface area of
1080 x 780 mm.
Roller fly net and blind are
mounted to the inner frame which can be adjusted independently or
combined.
Suitable for roof thickness
from 25-60 mm in combination with special fittings.
Frame colour: cream white (RAL
9001).
Technical Data
Weight (kg)
11
Cut out (mm)
960 x
655
Installation area (mm)
1080 x
780
Possible roof thickness (mm)
25 - 60
Max. opening angle (approx.)
55°
Item
Details
Item Code
Price
Seitz Heki 2
Caravan Rooflight - For 25-33mm Roofs
(installation kits are required for thicker roofs,
click here)
ZUB1127255
Seitz Heki
2 Deluxe
Caravan Rooflight
Seitz Heki
2 Deluxe Rooflight - The Exclusive Rooflight for Caravans
The highly successful Heki 2 has been improved even further. Four
integrated lights create a comfortable atmosphere and the innovative Duette honeycomb material offers the greatest possible thermal insulation
due to the hollow chamber construction.
An inner aluminium lining
which absorbs up to 99% of harmful UV rays
Four integrated 5 Watt bulbs
for soft, subdued lighting
Precision produced with
Duette honeycomb material
Blind and fly net mounted to
the inner frame, can be operated together or independently, by means of
two fixing bars
New fixing bars specially
developed to match the colours of the inner frame
Suitable for roof thickness
from 25 - 60 mm in combination with special fittings
Frame colour: cream white (RAL
9001)
Technical Data
Weight (kg)
11
Cut out (mm)
960 x 655
Installation area (mm)
1080 x 790
Possible roof thickness (mm)
25 - 60
Max. opening angle (approx.)
55°
Item
Details
Item Code
Price
Seitz Heki 2
Deluxe
Caravan Rooflight - For 25-33mm Roofs
(installation kits are required for thicker roofs,
click here)
ZUB133525
Seitz Heki
3 Plus Caravan Rooflight
Seitz Heki
3 Plus Rooflight -
Improved Shading With Pleated Fly Net
Enjoy more light and better ventilation with the Heki 3 Plus caravan
rooflight.
To improve the shading of your vehicle the Seitz Heki 3 Plus rooflight is equipped with a
pleated fly net. The Duette honeycomb system lets you enjoy excellent
thermal insulation and comfort while built in comfort lights add subdued
illumination to your caravan or motorhome.
Made of opaque, weather proof
ASA
Lateral runners reduce the
incidence of light between Duette honeycomb material and frame
Acrylic double-glazed dome
light (tinted in grey) can be opened up for ventilation to 70° maximum
when the vehicle is stationary
Large overlap of glazing
panel prevents water from penetrating when dome is raised
Inner frame with seamless
adjustable fly net, can be operated together with duette blind
Integraed energy saving light
(2 x 8 Watt) for soft, subdues illumination
Safe and easy operation,
thanks to winding handle, acrylic dome can be opened smoothly
The inovative duette
honeycomb materail ensures greatest possible thermal insulation and cosy
comfort
Robust locking system inside
the outer frame reduces the risk of unwelcome intrusion from the outside
Frame colour - cream white
(RAL9001)
Technical Data
Weight (kg)
15
Cut out (mm)
960 x 655
Installation area (mm)
1080 x 790
Possible roof thickness (mm)
25 - 60
Max. opening angle (approx.)
70°
Item
Details
Item Code
Price
Seitz Heki
3 Plus
Caravan Rooflight - For 25-33mm Roofs
(installation kits are required for thicker roofs,
click here)
ZUB133625
Seitz Heki
4 Plus Caravan Rooflight
Seitz Heki
4 Plus Rooflight -
With Rain Sensor and Pleated Fly Net
Enjoy more light and better ventilation by remote control with the Heki 4
Plus caravan rooflight. This advanced model is equipped with a
pleated fly net for better shading. The dome closes automatically when it
rains and the remote control allows easy control. The advanced
Duette honeycomb system ensures excellent thermal insulation, while built
in convenience lights add subdued illumination to your caravan or
motorhome.
Remote electric operation
Dome closes automatically if
it rains
Control lamp indicates
correct locking of dome
Easy installation
Frame made of weather proof
ASA
Lateral straps reduce the
degree of light between Duette honeycomb material and frame
Acrylic double-glazed dome
light (2 x 8 Watt) for soft, subdued illumination
Lights can be operated
seperatly
The inovative duette
honeycomb material enures greatest possible thermal insulation and cosy
comfort
Inner frame with seamlessly
adjustable fly net, can be operated together with Duette Blind
Robust locking system inside
the outer frame
Frame colour - cream white (RAL
9001)
Longitudinal or transverse
mounting
Technical Data
Weight (kg)
15.5
Cut out (mm)
960 x 655
Installation area (mm)
1080 x 790
Possible roof thickness (mm)
25 - 60
Max. opening angle (approx.)
70°
Item
Details
Item Code
Price
Seitz Heki
4 Plus
Caravan Rooflight - For 25-33mm roof
(installation kits are required for thicker roofs,
click here)
ZUB134225
Seitz Mini Heki
Caravan Rooflight
Seitz Mini Heki Rooflight
Small and smart rooflight specially designed for installation in
standard-sized dome lights (400 x 400 mm). The Mini Heki caravan rooflight
ensures a maximum incidence of light. Easy adjustment with operating
lever. Opens in three positions: completely open, half open and bad
weather position. No water can splash inside when the glass dome is in bad
weather position.
Double
glazed, aerodynamic
shaped glass dome made of unbreakable Polycarbonate and tinted light
grey.
Inner and
outer pane are glued together, so easy to clean
Opens in 3
positions: completely open, half
open and bad weather position
With the
glass overlapping the sides, and the outer frame stands up, so no water
can splash inside when the glass dome is in bad weather position
Easiest
possible adjustment of the glass dome by means of a handy operating
lever; the dome is automatically locked when closed
Frame made of
durable, weatherproof ASA
Version
without compulsory ventilation comes with lateral runners - reducing the
incidence of light between frame and simple-patterned blind
Available
with or without fixed ventilation
Technical Data
Weight (kg)
3.3
Cut out (mm)
400 x
400
Installation area (mm)
550 x
510
Possible roof thickness (mm)
25 -
60
Max. opening angle (approx.)
50°
Item
Details
Roof
Thickness
Item Code
Price
Seitz Mini Heki
Caravan Rooflight
Without
Fixed Ventilation
25 - 42 mm
ZUB13522501
Seitz Mini Heki
Caravan Rooflight
Without
Fixed Ventilation
43 - 60 mm
ZUB13522502
Seitz Mini Heki
Caravan Rooflight
With 15 sq
cm Fixed Ventilation
25 - 42 mm
ZUB13522503
Seitz Mini Heki
Caravan Rooflight
With 15 sq
cm Fixed Ventilation
43 - 60 mm
ZUB13522504
Seitz Midi Heki
Caravan Rooflight
Seitz Midi Heki Rooflight
- Big style ventilation comfort
The "big brother" of the successful Mini Heki, offers the same comfort
features and exceptional quality, but with different dimensions for
installation: 700 x 500mm. It's ideal for owners of vehicles where
Heki standard models could not be installed due to their specific
dimensions - now the Seitz Midi Heki offers the ideal solution.
Double glazed, aerodynamically shaped glass dome made
of unbreakable Polycarbonate and tinted light grey
Inner and outer pane are glued together, so easy to
clean
Opens in 3 positions: fully open, half open and bad
weather position
Can be opened up to 45°
With the glass overlapping the sides, and the outer
frame stands up, so no water can splash inside when the glass dome is in
bad weather position
Easiest possible adjustment of the glass dome by
means of a handy operating lever; the dome is automatically locked when
closed
Frame made of durable, weatherproof ASA
Die-cast finish prevents unwanted incidence of light
through the frame
Available with or without fixed ventilation
Technical Data
Weight (kg)
9
Cut out (mm)
700 x
500
Installation area (mm)
880 x
650
Possible roof thickness (mm)
25 -
60
Max. opening angle (approx.)
60°
Item
Details
Item Code
Price
Seitz Midi Heki
Caravan Rooflight - With
Fixed Ventilation
For 25-33mm
roof
(installation kits are required for thicker roofs,
click here)
ZUB13682501
Seitz Midi Heki
Caravan Rooflight - Without
Fixed Ventilation For 25-33mm roof
(installation kits are required for thicker roofs,
click here)
ZUB13682502
Installation Kits for
Heki 2, Heki 2 Deluxe, Heki 3 & Heki 4
Item
Details
Item Code
Price
Installation Kit for Heki 2, 2 Deluxe, 3 & 4 for
32-39mm roofs
ZUB1305
Installation Kit for Heki 2, 2 Deluxe, 3 & 4 for
39-46mm roofs
ZUB1306
Installation Kit for Heki 2, 2 Deluxe, 3 & 4 for
46-53mm roofs
ZUB1307
Installation Kit for Heki 2, 2 Deluxe, 3 & 4 for
53-60mm roofs
ZUB1308
Installation Kits for Midi Heki
Item
Details
Item Code
Price
Installation Kit for Midi Heki for 25-29mm roofs
ZUB1376
Installation Kit for Midi Heki for 30-34mm roofs
ZUB1377
Installation Kit for Midi Heki for 35-42mm roofs
ZUB1378
Installation Kit for Midi Heki for 43-52mm roofs
ZUB1379
Installation Kit for Midi Heki for 53-60mm roofs
ZUB1380
We stock
most Seitz windows and send them on a next day carrier.
