Dometic
Air Conditioner Units UK
Motorhome Air
Conditioning
|
Dometic motorhome air conditioners employ the
lightest and most efficient refrigeration systems, deliver cool, de-humidified
air and filter away dust and dirt particles. Just set the temperature you want
and soon it‘s nice and cool inside. On a cold morning, use the heating element
to chase away the chill. Dometic air conditioners can be powered through a mains
hook-up, a Dometic generator or inverter and even from the 230 Volt supply of
your vehicle.
The idea of going on holiday in your recreational
vehicle is to explore new ground – not going
without the comfort you are used to at home. A Dometic air conditioner
enables you to enjoy the same pleasant
temperatures wherever you are. Powered by strong
and energy-saving technology it offers high cooling performance for
optimum comfort. The humidity in the air is
effectively reduced, dirt and dust particles are filtered
out. That’s how Dometic air conditioners ensure you always travel
in comfort breathing clean, fresh air.
Take your pick:
the Dometic range offers air
conditioners in all performance categories – including models with
manual temperature control or automatic air conditioning, with
integrated heating or additional fresh air supply. Roof
mounting allows for maximum efficiency and use of space. An
ingenious system based on nature’s own example:
warm air is drawn in and cooled down, while cool air sinks down naturally.
The under-bench air conditioner is a genuine
innovation in climate control technology: supplied with a heat pump, it
offers cooling as well as heating. |
|
Dometic CA1000 Air Conditioner |
|




|
This air conditioner fits any
motorhome and any budget! The favourably
priced Dometic CA1000 air conditioner is
amazingly compact. At a flat height of 20 cm it
is ideal for installation in smaller caravans,
motorhomes and panel vans. The
powerful compressor system is quick and easy
to install – in an existing or newly cut roof opening. Due
to its low starting current, the CA1000 air
conditioner works simply everywhere and
without fail, even on campsites with low
electrical circuit protection. Two optional DC
kits are available for mobile operation. Small
is smart – welcome to the
compact class of vehicle air
conditioning!
 |
Super compact, aerodynamic design, low weight |
 |
Perfect installation results, air conditioner adjusts to
the roof thickness |
 |
Energy-saving, pleasantly quiet running |
 |
Two blower speeds, manual or automatic operation |
 |
Temperature and blower speed set by control panel |
 |
Designed for stationary operation (230
volts) |
 |
In combination with DC-Kit-1 or DC-Kit-3 also for
mobile operation (12 volts) |
 |
Impeccable operation on all European campsites due
to low starting current ( < 3 A
) |
|
|
Cooling Capacity |
1000 watts / 3400 Bty/h |
|
Power Consumption |
450
watts |
|
Input Voltage |
230 volts AC / 50Hz |
|
Current Consumption |
2.3 A |
|
Necessary Circuit Protection |
3 A delay fuse |
|
Number of Blower Speeds |
2 /
automatic |
|
Thermostat Temperature Control |
Yes |
|
Refrigerant |
R134a |
|
Dimensions [W x H x D] |
565 x 199 x 690mm |
|
Roof Opening / Roof Thickness |
400-435 x 400-435mm / 35 - 50mm |
|
Weight |
approx 22kg |
|
Test Marks |
TÜV/GS,
e-approved to EMC automotive directive |
|
Scope Of Delivery |
Roof air conditioner, mounting frame, air diffuser
unit, fixing materials, installation and operating instructions |
|
|
Item Details |
Item Code |
Price |
Buy Now |
|
Dometic CA1000 Motorhome Air
Conditioner |
DOM-9100100003 |
£ |
|
|
Dometic B1100S / B1500S Air Conditioners |
|



 |
Flat, aerodynamic and pleasantly quiet: the
B1100S motorhome air conditioner excels
for its high performance combined with low
energy consumption. That means it is even better
than the well proven
forerunner model, which has been chosen by
leading manufacturers of recreational vehicles for years.
Its ultra-flat construction reduces vibration and, what’s
more, makes installation even easier. The
Dometic B1500S motorhome air conditioner
represents one of Europe’s most popular air
conditioners in an optimised version.
Having the same size and aerodynamics as the
B1100S air conditioner, it offers an
extra 500 watts in performance. Both models
feature an extra-flat air diffuser unit which
gives you more headroom, e.g. for opening the bathroom
door without catching at the top.
 |
Flat, aerodynamic design |
 |
Perfect installation results, air conditioner adjusts
to the roof thickness |
 |
Extra-flat air diffuser unit |
 |
Pleasantly quiet running |
 |
Two-speed blower with improved air circulation |
 |
Temperature and blower speed set by control panel |
 |
Additional heating function |
 |
Safe operation, tilt-insensitive up to 10 degrees |
 |
Designed for stationary operation
(230 volts) |
 |
Circuit protection for campsites: |
 |
3 A delay fuse (B1100S),
4 A delay fuse (B1500S) |
| |
B110S |
B1500S |
|
Cooling Capacity |
1000 watts / 3400 Btu/h |
1500watts / 5200Btu/h |
|
Heating Capacity |
800 watts |
800 watts |
|
Power Consumption |
500/800 watts |
650/800 watts |
|
Input Voltage |
230 volts AC /
50Hz |
|
Current Consumption |
2.1 / 3.5 A |
2.9 / 3.5 A |
|
Necessary Circuit Protection |
3 A delay fuse |
4 A delay fuse |
|
Number of Blower Speeds |
2 |
|
Thermostat Temperature Control |
Yes |
|
Refrigerant |
R407c |
|
Dimensions [W x H x D] |
650 x 235 x 980mm |
|
Roof Opening |
400 x 400mm |
|
Roof Thickness |
25 - 45mm / up to 75mm |
|
Weight |
approx 29kg |
approx 33kg |
|
Test Marks |
E-approved to EMC automotive directive |
|
Scope Of Delivery |
Roof air conditioner, mounting frame, air diffuser
unit, fixing materials, installation and operating instructions |
|
|
Item Details |
Item Code |
Price |
Buy Now |
|
Dometic B1100S Motorhome Air
Conditioner |
DOM-9100100004 |
£ |
|
|
Dometic B1500S Motorhome Air
Conditioner |
DOM-9100100005 |
£ |
|
|
Dometic B1600 / B1600 Plus Air Conditioners |




In Stock & sent on next
working day carrier!! |
Take one of Europe’s most popular air conditioning
systems, and provide it with an improved air
distribution system. The result: the
compressor roof air conditioner Dometic
B1600PLUS motorhome air conditioner.
Designed for small and medium recreation vehicles, quick
and easy to install. It delivers fresh, dehumidified air free
from dust and dirt. Thanks to a patented diffuser system,
air distribution is possible front or back separately, or both
front and back together. So far, all that’s exactly the same
as for the popular B1600 basic model.
 |
Flat, aerodynamic design |
 |
Perfect installation results, air conditioner adjusts
to the roof thickness |
 |
Pleasantly quiet running |
 |
Individual air flow regulation with automatic blower
control |
 |
Comfortable remote control (B1600PLUS) |
 |
Control panel with integrated lighting
(B1600PLUS) |
 |
Additional heating function |
 |
Safe operation, tilt-insensitive up to 10 degrees |
 |
Designed for stationary operation
(230 volts) |
 |
In combination with DC-Kit-2 or DC-Kit-3
also for mobile operation (12 volts) |
 |
Circuit protection for campsites: 4 A delay fuse |
|
Cooling Capacity |
1000 watts / 5200 Btu/h |
|
Heating Capacity |
800 watts |
|
Power Consumption |
650 / 800 watts |
|
Input Voltage |
230 volts AC /
50Hz |
|
Current Consumption |
2.9 / 3.5 A |
|
Necessary Circuit Protection |
4 A delay fuse |
|
Number of Blower Speeds |
B1600: 2 , B1600 Plus:
4 / automatic |
|
Thermostat Temperature Control |
Yes |
|
Refrigerant |
R407c |
|
Dimensions [W x H x D] |
650 x 235 x 980mm |
|
Roof Opening |
400 x 400mm |
|
Roof Thickness |
30 - 80mm |
|
Weight |
Approx 33kg |
|
Test Marks |
E-approved to EMC automotive directive |
|
Scope Of Delivery |
Roof air conditioner, remote control [not for B1600], air diffuser
unit, mounting frame, fixing materials, installation and operating instructions |
|
|
Item Details |
Item Code |
Price |
Buy Now |
|
Dometic B1600 Motorhome Air
Conditioner |
Discontinued |
£ |
|
|
Dometic B1600 Plus Motorhome Air
Conditioner |
DOM-9100100007 |
£ |
|
|
Dometic B2200 Air Conditioner |
|



In Stock & sent on next
working day carrier!! |
An elegant installation result inside and out. High
performance, low vibration and noise level
thanks to advanced technology and aerodynamic
design. The Dometic B2200 motorhome air
conditioner creates a perfect climate on
board medium and large vehicles.
That’s largely due to its innovative air diffuser system. Like
the smaller sister model, Dometic B1600PLUS, air distribution
is possible front or back as well as to the sides, and
the fan speeds are individually adjustable. The temperature
and the blower speed are set by remote control.
 |
Flat, aerodynamic design |
 |
Perfect installation results, air conditioner adjusts to
the roof thickness |
 |
Pleasantly quiet running |
 |
Individual air flow regulation with automatic blower
control |
 |
Comfortable remote control of temperature
and blower speed |
 |
Control panel with integrated lighting |
 |
Additional, high-performance heating function |
 |
Safe operation, tilt-insensitive up to 10 degrees |
 |
Designed for stationary operation (230
volts) |
 |
In combination with DC-Kit-2 or DC-Kit-3 also for
mobile operation (12 volts) |
 | Circuit protection for campsites: 5 A delay fuse |
|
Cooling Capacity |
2050 watts / 7000 Btu/h |
|
Heating Capacity |
1200 watts |
|
Power Consumption |
910 / 1200 watts |
|
Input Voltage |
230 volts AC /
50Hz |
|
Current Consumption |
4.0 / 5.2 A |
|
Necessary Circuit Protection |
5 A delay fuse |
|
Number of Blower Speeds |
4 / automatic |
|
Thermostat Temperature Control |
Yes |
|
Refrigerant |
R407c |
|
Dimensions [W x H x D] |
650 x 235 x 980mm |
|
Roof Opening |
400 x 400mm |
|
Roof Thickness |
30 - 80mm |
|
Weight |
Approx 33kg |
|
Test Marks |
E-approved to EMC automotive directive |
|
Scope Of Delivery |
Roof air conditioner, remote control, air diffuser
unit, mounting frame, fixing materials, installation and operating instructions |
|
|
Item Details |
Item Code |
Price |
Buy Now |
|
Dometic B2200 Motorhome Air
Conditioner |
DOM-9100100009 |
£ |
|
|
Dometic CA2500 Air Conditioner |



 |
Do you have a large or medium-sized camper
vehicle? Welcome to your personal climate
summit! The Dometic CA2500 motorhome air conditioner
has one feature that sets it apart from all
other camper air conditioners available in the
market: the additional fresh air mode with the
patented fresh air flap. This pleasant and
battery-friendly function should be used
whenever the temperature outside is lower than the temperature
inside the vehicle – at night, for instance, or on
warm spring and autumn days when the sun radiation is
strong enough to heat up the vehicle. Moreover, the
CA2500 provides extraordinary performance at modest
energy consumption as well as many details for extra
comfort and convenience.
 |
Additional fresh air mode with patented fresh air flap |
 |
Perfect installation results, air conditioner adjusts to
the roof thickness |
 |
Optimal air distribution inside the vehicle
with individually adjustable air jets |
 |
Two blower speeds, manual or automatic operation |
 |
Comfortable remote control for all functions |
 |
Safe operation, tilt-insensitive up to 10 degrees |
 |
Designed for stationary operation (230
volts) |
 |
In combination with DC-Kit-2 or DC-Kit-3 also for
mobile operation (12 volts) |
 | Circuit protection for campsites: 5 A delay fuse |
|
Cooling Capacity |
2500 watts / 8500 Btu/h |
|
Heating Capacity |
1600 watts |
|
Power Consumption |
1150 / 1600 / 80 watts |
|
Input Voltage |
230 volts AC /
50Hz |
|
Current Consumption |
4.4 / 7.4 / 0.3 A |
|
Necessary Circuit Protection |
5 A delay fuse |
|
Number of Blower Speeds |
2 / automatic |
|
Thermostat Temperature Control |
Yes |
|
Refrigerant |
R407c |
|
Dimensions [W x H x D] |
670 x 238 x 1150mm |
|
Roof Opening |
400 - 400mm x 400 - 435mm |
|
Roof Thickness |
28 - 100mm |
|
Weight |
Approx 45kg |
|
Test Marks |
E-approved to EMC automotive directive |
|
Scope Of Delivery |
Roof air conditioner, remote control, air diffuser
unit, mounting frame, fixing materials, installation and operating instructions |
|
|
Item Details |
Item Code |
Price |
Buy Now |
|
Dometic CA2500 Motorhome Air
Conditioner |
DOM-9100100001 |
£ |
|
|
Dometic B3200 Air Conditioner |
|


 |
Welcome to the professional class!
Its powerful cooling capacity makes the Dometic
B3200 motorhome air conditioner ideal for
use in large motorhomes and the commercial
sector. No matter whether it is scorching hot or
freezing cold outside – you can always depend on
the B3200. It cools or heats effectively and
quietly, delivering clean, dehumidified air. The
new, ergonomic air diffuser unit is child’s play
to use.
 |
The most powerful air conditioner in the Dometic range |
 |
Perfect installation results, air conditioner adjusts to
the roof thickness |
 |
Pleasantly quiet running |
 |
Three blower speeds for maximum flexibility |
 |
Temperature and blower speed set by control panel |
 |
Additional, powerful heating function
(1600 watts) |
 |
Safe operation, tilt-insensitive up to 8 degrees |
 |
Designed for stationary operation (230
volts) |
 |
Mobile operation (230 volts)
possible with generators |
 | Circuit protection for campsites: 7 A delay fuse |
|
Cooling Capacity |
3200 watts / 10900 Btu/h |
|
Heating Capacity |
1600 watts |
|
Power Consumption |
1350 / 1600 watts |
|
Input Voltage |
230 volts AC /
50Hz |
|
Current Consumption |
6.3 / 6.9 A |
|
Necessary Circuit Protection |
7 A delay fuse |
|
Number of Blower Speeds |
3 |
|
Thermostat Temperature Control |
Yes |
|
Refrigerant |
R407c |
|
Dimensions [W x H x D] |
737 x 245 x 1025mm |
|
Roof Opening |
355 x 355mm |
|
Roof Thickness |
110mm |
|
Weight |
Approx 45kg |
|
Test Marks |
E-approved to EMC automotive directive |
|
Scope Of Delivery |
Roof air conditioner, air diffuser
unit, mounting frame, fixing materials, installation and operating instructions |
|
|
Item Details |
Item Code |
Price |
Buy Now |
|
Dometic B3200 Motorhome Air
Conditioner |
DOM-B3200-1112 |
£ |
|
|
Dometic HB2500 Air Conditioner |
|


In Stock & sent on next
working day carrier!! |
Experience the world’s first under-bench
motorhome air conditioner with genuine
heating function! Regardless of
whether it is tropically hot or
unpleasantly cold outside: the climate inside
your vehicle is always just right. Based on
efficient heat pump technology the Dometic
HB2500 provides high performance at low energy
consumption. It purifies and dehumidifies the air, cools
or warms it. The air is evenly
distributed to the different areas of the
vehicle via three outlets. The position of these outlets is
variable and can be individually adapted to your vehicle. All
functions, which include night-time control and time
programming, can be comfortably set by remote control.
The benefits of under-bench installation are obvious: roof
window, outer dimensions and the physical properties of
your vehicle remain unaffected.
 |
Energy-efficient heat pump system for cooling and
heating |
 |
No extra roof load, roof window is retained |
 |
Three blower speeds, air distribution can be adjusted
as required |
 |
Variable position of the air outlets |
 |
Low-noise air circulation |
 |
Low weight |
 |
High operating comfort with multi-functional remote
control |
 |
Designed for stationary operation (230
volts) |
 |
In combination with DC-Kit-3 also for mobile operation
(12 volts) |
 | Circuit protection for campsites: 6 A delay fuse |
|
Cooling Capacity |
2500 watts / 8500 Btu/h |
|
Heating Capacity |
3000 watts |
|
Power Consumption |
900 / 1100 watts |
|
Input Voltage |
230 volts AC /
50Hz |
|
Current Consumption |
3.9 / 4.8 A |
|
Necessary Circuit Protection |
6 A delay fuse |
|
Number of Blower Speeds |
3 |
|
Thermostat Temperature Control |
Yes |
|
Refrigerant |
R410a |
|
Dimensions [W x H x D] |
400 x
280 x 710mm |
|
Weight |
Approx 24.9kg |
|
Test Marks |
E-approved to EMC automotive directive |
|
Scope Of Delivery |
Air conditioner, remote control, IR receiver, fixing
materials, installation and operating instructions |
|
|
Item Details |
Item Code |
Price |
Buy Now |
|
Dometic HB2500 Motorhome Air
Conditioner |
DOM-9100100010 |
£ |
|
| Circular Air Inlet Grille
(Ø190mm) |
DOM-9100300018 |
£ |
|
| Rectangular Air Inlet
Grille (240mm x 240mm) |
DOM-9100300017 |
£ |
|
| Air Outlet Grille
(Ø60mm) |
DOM-9100300016 |
£ |
|
| Flexible Ducting 10m |
DOM-9100300019 |
£ |
|

Motorhome Air
Conditioner DC Kits
This table shows you which DC Kits are
suitable for each air conditioning unit, the 'X' indicates which which kits are
suitable.
| |
DC-Kit 1 |
DC-Kit 2 |
DC-Kit 3 |
| Dometic
CA1000 |
X |
|
X |
|
Dometic B1600 |
|
X |
X |
| Dometic
B1600 Plus |
|
X |
X |
|
Dometic B2200 |
|
X |
X |
| Dometic
CA2500 |
|
X |
X |
|
Dometic HB2500 |
|
|
X |
|
Dometic DC-Kit 1 |
 |
|
Current Consumption [12 volts
DC] |
30 to 40 A |
|
Recommended Generator Capacity |
≥ 75 A |
|
Recommended Total Battery
Capacity |
≥ 80 Ah |
|
Continuous Output |
1000 watts |
|
Dimensions [W x H x D] |
210 x
77 x 300mm |
|
Scope Of Delivery: Inverter [single-wave-like
output voltage, with mains priority circuit], remote control
including 5m control cable, 2 battery cables 16mm² [1.5m long], 230
volt connection cable, charging current distributor with relay. |
|
|
Dometic
DC Kit 1 |
DOM-9100300003 |
£ |
|
|
Dometic DC-Kit
2 |
 |
|
Current Consumption [12 volts
DC] |
90 A max |
|
Recommended Generator Capacity |
≥ 90 A |
|
Recommended Total Battery
Capacity |
≥ 100 Ah |
|
Continuous Output |
1600 watts |
|
Dimensions [W x H x D] |
210 x
77 x 410mm |
|
Scope Of Delivery: Inverter [single-wave-like
output voltage, with mains priority circuit], remote control
including 5m control cable, 2 battery cables 25mm² [1.5m long], 230
volt connection cable, charging current distributor with relay. |
|
|
Dometic
DC Kit 2 |
DOM-9100300001 |
£ |
|
|
Dometic DC-Kit 3 |
 |
|
Current Consumption [12 volts
DC] |
74 A max |
|
Recommended Generator Capacity |
≥ 90 A |
|
Recommended Total Battery
Capacity |
≥ 100 Ah |
|
Continuous Output |
1500 watts |
|
Dimensions [W x H x D]
Inverter
Mains Priority Circuit |
191 x 88 x 415mm
190 x 80 x 80mm |
|
Scope Of Delivery: Inverter [single-wave-like
output voltage, with mains priority circuit], remote control
including 5m control cable, 2 battery cables 25mm² [1.5m long], 230
volt connection cable, charging current distributor with relay. |
|
|
Dometic
DC Kit 3 |
DOM-9100300002 |
£ |
|
Purchasing
Phone or fax your credit card details or send
a cheque to the address below and make it payable to Jacksons Leisure Supplies.
We will send the goods to you using a recognised delivery service as quickly as
possible or once your cheque has cleared. Non U.K. customers please tell us
where you are and we will let you know how to make your purchase and what
additional costs may be involved.
To see what else we do visit our main index just click here.
Contact Information
- Jacksons Leisure Supplies
-
Telephone
+44 (0151) 334 0222
FAX
+44 (0151) 343 0223
Most items
can be picked up from our warehouse, ring for directions
2 Woodway Court, Thursby Road, Croft Business Park, Bromborough, Wirral, CH62
3PR, United Kingdom
- Electronic mail
- General Information: sales@jacksons-camping.co.uk
Sales: sales@jacksons-camping.co.uk
Last modified:
09-06-10
|
