Fibre Optic Paver Kit Lighting
Our fibre optic paver lighting kits are the perfect
solution to floor level mood lighting, inside or out*. These
fibre optic lighting kits are
also unique in that the fittings stay cool and are safe to walk on, of course
they also allow for a dazzling range of lighting effects.
The fittings of these
fibre optic lighting kits are manufactured from the highest quality
polished stainless steel and glass and are designed to last a lifetime.
They can be installed in: Wooden floors, decking, paving, stair skirting,
concrete and are typically used as marker lights for pathways or entrances, wall
washing inside or out, up lighting columns or archways and mood lighting in any
room in the house, including wet rooms and pool areas.
weatherproof enclosure required if light source to be located outside.
The
small fibre optic paver kit and
decking kits are the perfect lighting solutions for installation in a wide range of flooring materials such as solid wood, laminates, concrete and paving, both indoors and outdoors (with a
light source enclosure). The fibre optic kits are very easy to install, with
complete instructions provided, and very safe – no electricity flows through the
neat 50mm stainless steel pavers. The light source can cycle through
six
colours or remain static on one colour at the flick of a switch.
|
Small
paver kit |
Small fibre optic lights kit contains:
100w tungsten halogen light source
(280mm long, 125mm high, 166mm wide) feeding 4 fibre optic cables with stainless
steel paver fittings. Light source has 4 colour colour wheel with separate feed
for static single colour or cycle through 4 colours. Customised colour wheels
available.
Fibre optics light
source requires 2 x 240v supplies, 1 for lamp and 1 for colour wheel control.
Comes fitted with 2 x household plugs.
All kits come with a 6 colour wheel
|
Picture above is just one
example of a fibre optic Paver kits. |
|
Cables with small kit.
 |
1 x 1m |
|
1 x 2m |
|
1 x 3m |
|
1 x 4m |

100w tungsten halogen lightsource with 2 plugs - one to
power the lamp and one to switch the colourwheel off or on. Dimensions:
(L)286mm x (W)155mm x (H)119mm. |

Please select the fitting you
require, round or the square?
If
you are installing the light source outside it must be installed in a waterproof
enclosure.
|
|
Medium
paver kit A |
Medium fibre optics decking &
paver Kit
With the same fibre optics light source specifications as the
paver and decking kits, the medium paver decking kit features 6 fibre optic tails for a linear installation.
Fibre optics light
source requires 2 x 240v supplies, 1 for lamp and 1 for colour wheel control.
Comes fitted with 2 x household plugs.
All kits come with a 6 colour wheel
|
Picture above is just one
example of a fibre optic Paver kits. |
|
Cables with medium
kit:
|
3 x 2.0m
|
|
3 x 3.0m
|
100w tungsten halogen lightsource with 2 plugs
- one to power the lamp and one to switch the colourwheel off or on. Dimensions:
(L)280mm x (W)166mm x (H)125mm.
|
Please select the fitting you
require, round or the square?
If
you are installing the light source outside it must be installed in a waterproof
enclosure.
|
|
Medium
paver kit B |
Medium fibre optics decking &
paver Kit
With the same fibre optics light source specifications as the
paver and decking kits, the medium paver decking kit features 6 fibre optic tails for a linear installation.
Fibre optics light
source requires 2 x 240v supplies, 1 for lamp and 1 for colour wheel control.
Comes fitted with 2 x household plugs.
All kits come with a 6 colour wheel
|
Picture above is just one
example of a fibre optic Paver kits. |
|
Cables with medium
kit:
|
1 x 1.5m |
|
1 x
2.0m |
|
1 x 2.5m |
|
1 x
3.0m |
|
1 x 3.5m |
|
1 x
4.0m |
100w tungsten halogen lightsource with 2
plugs - one to power the lamp and one to switch the colourwheel off or on.
Dimensions: (L)280mm x (W)166mm x (H)125mm. |
Please select the fitting you
require, round or the square?
If
you are installing the light source outside it must be installed in a waterproof
enclosure.
|
|
Large
paver kit A |
Fibre optic kit contents:
100w tungsten halogen light source feeding 8 fibre optic cables with stainless steel paver fittings.
Light source has 4 colour
colour wheel with separate feed for static single colour or cycle through 4 colours. Customised
colour heels available.
Fibre optics light
source requires 2 x 240v supplies, 1 for lamp and 1 for colour wheel control.
Comes fitted with 2 x household plugs.
All kits come with a 6 colour wheel
|
Picture above is just one
example of a fibre optic Paver kits. |
|
Cables with large
kit A:
|
2 x 2m |
|
2 x 3m |
|
2 x 4m |
|
2 x 5m |
100w tungsten halogen lightsource with 2
plugs - one to power the lamp and one to switch the colourwheel off or on.
Dimensions: (L)280mm x (W)166mm x (H)125mm. |
Please select the fitting you
require, round or the square?
If
you are installing the light source outside it must be installed in a waterproof
enclosure.
|
|
Large
paver kit B |
Fibre optic kit contents:
100w tungsten halogen light source feeding 8 fibre optic cables with stainless steel paver fittings.
Light source has 4 colour
colour wheel with separate feed for static single colour or cycle through 4 colours. Customised
colour heels available.
Fibre optics light
source requires 2 x 240v supplies, 1 for lamp and 1 for colour wheel control.
Comes fitted with 2 x household plugs.
All kits come with a 6 colour wheel
|
Picture above is just one
example of a fibre optic Paver kits. |
|
Cables with large
kit B:
|
2 x
4m |
|
2 x
5m |
|
2 x
6m |
|
2 x
7m |
100w tungsten halogen lightsource with 2
plugs - one to power the lamp and one to switch the colourwheel off or on.
Dimensions: (L)280mm x (W)166mm x (H)125mm. |
Please select the fitting you
require, round or the square?
If
you are installing the light source outside it must be installed in a waterproof
enclosure.
|
|
Extra Large
paver kit A |
Fibre optic kit contents:
100w tungsten halogen light source feeding 8 fibre optic cables with stainless steel paver fittings.
Light source has 4 colour
colour wheel with separate feed for static single colour or cycle through 4 colours. Customised
colour heels available.
Fibre optics light
source requires 2 x 240v supplies, 1 for lamp and 1 for colour wheel control.
Comes fitted with 2 x household plugs.
All kits come with a 6 colour wheel
|
Picture above is just one
example of a fibre optic Paver kits. |
|
Cables with Extra large
kit A:
|
1 Tail @ 3.0m
|
|
1 Tail @ 3.5m
|
|
1 Tail @ 4.0m
|
|
1 Tail @ 4.5m
|
|
1 Tail @ 5.0m
|
|
1 Tail @ 5.5m
|
|
1 Tail @ 6.0m
|
|
1 Tail @ 6.5m
|
|
1 Tail @ 7.0m
|
|
1 Tail @ 7.5m
|
100w tungsten halogen lightsource with 2 plugs
- one to power the lamp and one to switch the colourwheel off or on. Dimensions:
(L)280mm x (W)166mm x (H)125mm.
|
Please select the fitting you
require, round or the square?
If
you are installing the light source outside it must be installed in a waterproof
enclosure.
|
|
Extra Large
paver kit B |
Fibre optic kit contents:
100w tungsten halogen light source feeding 8 fibre optic cables with stainless steel paver fittings.
Light source has 4 colour
colour wheel with separate feed for static single colour or cycle through 4 colours. Customised
colour heels available.
Fibre optics light
source requires 2 x 240v supplies, 1 for lamp and 1 for colour wheel control.
Comes fitted with 2 x household plugs.
All kits come with a 6 colour wheel
|
Picture above is just one
example of a fibre optic Paver kits. |
|
Cables with Extra large
kit B:
|
2 Tails @ 3.0m
|
|
2 Tails @ 4.0m
|
|
2 Tails @ 5.0m
|
|
2 Tails @ 6.0m
|
|
2 Tails @ 7.0m
|
100w tungsten halogen lightsource with 2 plugs
- one to power the lamp and one to switch the colourwheel off or on. Dimensions:
(L)280mm x (W)166mm x (H)125mm.
|
Please select the fitting you
require, round or the square?
If
you are installing the light source outside it must be installed in a waterproof
enclosure.
|
